90×90×15MM SERIES
Bearing Type: Two ball bearing Sleeve bearing
Rated Voltage: 12V
Material：Housing Plastic (UL：94V-0)、Impeller Plastlc (UL：94V-0)
Protection：Auto-Restart /Impedance
Operating Temp：~10~70°C
| Model | Bearing | Rated Voltage | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | VDC | Amp | Watt | R.P.M | CFM | mm-H20 | dB(A) | |
| Two Ball Bearing | 12 | 0.40 | 4.80 | 2700 | 51.68 | 2.64 | 40.2 |
